Tamiya Fighter NXGEN (DT-04) TAM-58741

Here is another, hot entry to our Fighter Buggy series.

This is an R/C model assembly kit inspired by full size single-seater racing buggies popular in America. The new DT-04 - a 2WD rear-wheel drive buggy chassis - of course offers ease of assembly and  lively performance, which is a characteristic of this series.

This product name "NXGEN" is based upon the English word "Next Generation" and as you can guess from the name, it gives improved off-road performance  and a wealth of setups. Also, front and rear suspension arms, gears and gearbox are from DT-02 and DT-03 chassis cars, and option parts from DT-02 and DT-03 chassis can be used for this chassis. Body will also be interesting part to see!

DT-04 Chassis: Lively RWD Performance
This is a rear-wheel drive buggy chassis which offers ease of assembly and lively performance. It has an inline battery pack position, and a rear-mounted motor to give the rear wheels plenty of traction.

The sealed gearbox has a built-in gear differential for smooth cornering and helps keep out dust and dirt. Two wheelbases can be selected: 265mm for emphasis on handling or 280mm for emphasis on stability. 4-wheel independent double wishbone suspension with long arms employs CVA oil dampers. Front skid angle is 22.5 degrees to ensure both controllability and powerful performance.

The 3-piece steering tie-rod gives true steering. Here, the chassis features ribbed tires on the front, and grippy square spike tires on the rear.

About the Model
• This is a 1/10 scale R/C model assembly kit. Length: 395mm (with 265mm wheelbase) / 404mm (with 280mm wheelbase), height: 120mm, width: 248mm.
• Please kindly note that the package also contained the mistake (described as Length: 395mm (with 280mm wheelbase)). We plan to revise the package from the next production.
• Two wheelbases can be selected: 265mm for emphasis on handling or 280mm for emphasis on stability. Reassemble the front section (arms, etc.) to switch between two different wheelbases. (*) (Illustration 1)
• The distinctive body features multiple body panels connected to pipe frames, a design inspired by full size racing buggies.
• Its 2WD rear-wheel drive chassis has a lightweight, durable bathtub frame which is newly designed. (*)
• The chassis has an inline battery pack position, and a rear-mounted motor to give the rear wheels plenty of traction. (Chassis illustration)
• The sealed gearbox has a built-in gear differential for smooth cornering and helps keep out dust and dirt. (*)
• Side pontoons have the ESC in the left and the receiver in the right
